- Outlet Port Connection Size: 1/4 in
- Inlet Port Connection Size: 1/4 in
- Pressure (PSI): 0 to 30
- Operating Temp. Range (F): 50 to 120
- Operating Temperature - Minimum: -20 Degrees F
- Control Signal: Proportional
Specifications
| Part Number | T-5800-1 |
| Brand | Johnson Controls |
| Application | Discharge Air Temperature Control, Humidity Control, Water Temperature Control |
| Output | 3 to 15 |
| Width | 5 in |
| Type | Single Input |
| Height | 5 in |
| Depth | 5 in |
| Overall Length | 4 9/16 in |
| Outlet Port Connection Size | 1/4 in |
| Overall Depth | 5 3/4 in |
| Inlet Port Connection Size | 1/4 in |
| Overall Width | 4 3/4 in |
| Item | Pneumatic Receiver Controller |
| Air Consumption | 25 scim |
| Control Type | Proportional |
| Air Input Range (PSI) | 18 to 22 |
| Pressure (PSI) | 0 to 30 |
| Gauge | Yes |
| Air Consumption (SCFM) | 45 scfm |
| Operating Temp. Range (F) | 50 to 120 |
| Mounting Style | Surface |
| Operating Temperature - Minimum | -20 Degrees F |
| Control Signal | Proportional |
| Number of Inputs | Single Input |
| Outlet Port Connection Type | Barbed Hose |
| Operating Humidity - Minimum | 10 % |
| Outlet Port Connection Gender | Male |
| Adjustable Integral Time - Minimum | 0.6 sec |
| Number of Inlet Ports | 1 |
| Control Action | Direct Acting/Reverse Acting |
| Adjustable Integral Time - Maximum | 30 min |
| Operating Humidity - Maximum | 90 % |
| Operating Temperature - Maximum | 120 Degrees F |
| Signal Pressure - Maximum | 9 psi |
| Inlet Port Connection Type | Barbed Hose |
| Cover Material | Plastic |
| Signal Pressure - Minimum | 3 psi |
| Inlet Port Connection Gender | Male |
| Body Material | Plastic |
| Supply Pressure | 20 psi |
Description
The Johnson Controls T-5800-1 is a single-input pneumatic receiver controller with proportional control type. This controller modulates a pneumatic output signal in response to a single input, functioning within a 0 to 30 PSI pressure range and an operating temperature range of 50 to 120 degrees Fahrenheit. It is applied in discharge air temperature control, humidity control, and water temperature control systems.
