- Proximity Sensor Power Requirement: 12 to 48V DC
- Proximity Sensor Operating Frequency: 50 Hz
- Proximity Sensor Output Circuit Type: PNP
- Max. Detecting Distance: 60 mm
- Proximity Sensor Electrical Connection Screw: Clamp Terminal
- Output Mode: NO/NC
Specifications
| Part Number | XSDH607339H7 |
| Brand | Telemecanique Sensors |
| Item | Inductive Rectangular Proximity Sensor |
| Proximity Sensor Power Requirement | 12 to 48V DC |
| Proximity Sensor Operating Frequency | 50 Hz |
| Proximity Sensor Output Circuit Type | PNP |
| Max. Detecting Distance | 60 mm |
| Proximity Sensor Electrical Connection Screw | Clamp Terminal |
| Output Mode | NO/NC |
| NEMA Rating | 12, 13, 3, 4, 6 |
| IP Rating | IP67 |
| Case Material | Plastic |
| Length | 80 mm |
| Operating Temp. | Range -13 Degrees to 158 Degrees F |
| Max. Current Load | 200mA |
| Features | Inductive, Unshielded |
| UPC | 785901455820 |
Description
The Telemecanique Sensors XSDH607339H7 is an inductive rectangular proximity sensor with a plastic case and unshielded design. It operates on 12 to 48V DC, has a PNP output circuit type with NO/NC output mode, and offers a maximum detecting distance of 60 mm. The sensor features a clamp terminal electrical connection, IP67 rating, and an operating temperature range of -13 to 158 degrees F.
