- Bore Diameter: 20 mm
- Maximum Operating Pressure: 1 MPa
- Inlet Size: M5 x 0.8
- Air Inlet Type Metric: Standard
- Maximum Output Torque: 3.66 N-m
- Cushion Type: Rubber Cushion
Specifications
| Part Number | MSQB20A |
| Brand | SMC |
| Item | Rotary Table |
| Bore Diameter | 20 mm |
| Maximum Operating Pressure | 1 MPa |
| Inlet Size | M5 x 0.8 |
| Air Inlet Type Metric | Standard |
| Maximum Output Torque | 3.66 N-m |
| Cushion Type | Rubber Cushion |
| Table Material Finish | Anodized |
| Body Material Finish | Anodized |
| Minimum Rotation Angle | 43 Degrees |
| Bearing | Retainer Material Aluminum Alloy |
| Body Height | 37 mm |
| Body Material Aluminum | Alloy |
| Allowable Kinetic Energy | 0.03 J |
| Table Size | 20 |
| Maximum Rotation Angle | 190 Degrees |
| Overall Length | 142 mm |
| UPC | 190735677612 |
Description
The SMC MSQB20A is a rotary table with a 20 mm bore diameter and an M5 x 0.8 inlet size. It has a maximum operating pressure of 1 MPa, a maximum output torque of 3.66 N-m, and an allowable kinetic energy of 0.03 J. The anodized aluminum body measures 142 mm in overall length and 37 mm in height, with a rotation angle range of 43 to 190 degrees.
Confirm the part number against your existing unit or equipment before ordering to ensure correct fit.
