- Ball Material: CPVC
- Nominal Valve Size: 2 in
- Maximum Pressure - Operating: 250 psi
- Actuator Operation: 90 Degrees
- Valve Body Style: Straight
- Seat Material: PTFE
Specifications
| Part Number | HRSTBH220STE |
| Brand | Hayward Flow Control |
| Item | Electrically Actuated Two-Way Ball Valve |
| Ball Material | CPVC |
| Nominal Valve Size | 2 in |
| Maximum Pressure - Operating | 250 psi |
| Actuator Operation | 90 Degrees |
| Valve Body Style | Straight |
| Seat Material | PTFE |
| Seal Material | EPDM |
| Voltage | 120V AC |
| Fail Safe Position Fail | Last |
| IP Rating | IP67 |
| Actuator Cycle Time - 90 Degrees | 9 sec |
| Valve Construction | Three-Piece |
| Actuator Features | Auxiliary Limit Switch, Manual Override, Position Indicator, Thermal Overload Protection |
| Connection Gender - Side | 1 Female |
Description
The Hayward Flow Control HRSTBH220STE is an electrically actuated two-way ball valve with a 2-inch nominal size and a straight, three-piece CPVC body. It operates at a maximum pressure of 250 psi with a 120V AC actuator that completes a 90-degree cycle in 9 seconds. The valve includes PTFE seats, EPDM seals, an IP67 rating, and actuator features such as a manual override, position indicator, and thermal overload protection.
Confirm the part number against your existing unit or equipment before ordering to ensure correct fit.
