- Hose Inside Dia.: 1 1/2 in
- Hose Outside Dia.: 2 1/8 in
- Hose Length: 10 ft
- Hose Tube Material Synthetic: Rubber
- Hose Cover Material Synthetic: Rubber
- Hose Reinforcement Type: Spiral
Specifications
| Part Number | FC254-24-10 |
| Brand | Eaton Aeroquip |
| Item | Hydraulic Hose |
| Hose Inside Dia. | 1 1/2 in |
| Hose Outside Dia. | 2 1/8 in |
| Hose Length | 10 ft |
| Hose Tube Material Synthetic | Rubber |
| Hose Cover Material Synthetic | Rubber |
| Hose Reinforcement Type | Spiral |
| Hose Reinforcement Material | Carbon Steel |
| Hose | Braid Layers No Braid |
| Hose Color | Black |
| Burst Pressure | 17,400 psi |
| Max. Working Pressure @ 70 F | 4,350 psi |
| Temp. | Range -40 Degrees to 260 Degrees F |
| Standards | ABS, DNV |
| EN | 856 4SP |
| SAE | 100R11 |
| Bend Radius | 20 in |
| Features | MSHA, USCG/MMT |
Description
The Eaton Aeroquip FC254-24-10 is a hydraulic hose with an inside diameter of 1 1/2 in, an outside diameter of 2 1/8 in, and a length of 10 ft. It has a synthetic rubber tube and cover, spiral carbon steel reinforcement, and a maximum working pressure of 4,350 psi at 70 F. The hose has a burst pressure of 17,400 psi, a temperature range of -40 to 260 degrees F, and a bend radius of 20 in.
Confirm the part number against your existing unit or equipment before ordering to ensure correct fit.
