- Input Connection Type: Indirect Drive
- Gear Type: Worm
- Output Shaft Type: Round
- Maximum Output Speed: 172 RPM
- Motor: Frame Designation Solid Input Shaft
- Worm Center Distance: 2 in
Specifications
| Part Number | E20XWNS, 10:1 |
| Brand | Winsmith |
| Item | Speed Reducer |
| Input Connection Type | Indirect Drive |
| Gear Type | Worm |
| Output Shaft Type | Round |
| Maximum Output Speed | 172 RPM |
| Motor | Frame Designation Solid Input Shaft |
| Worm Center Distance | 2 in |
| Base to Center | 2.13 in |
| Gear Ratio | 10:1 |
| Rotation | CW/CCW |
| Maximum Input Horsepower | 2 hp |
| Maximum Output Torque | 687 in-lb |
| Overhung Load Capacity | 150 lb |
| Mounting Orientation | Any Angle |
| Housing Material Cast | Iron |
| Housing Material Finish | Epoxy Coating System |
Description
The Winsmith E20XWNS, 10:1 is a worm gear speed reducer with an indirect drive input connection and a round output shaft. It has a 10:1 gear ratio, a 2-inch worm center distance, and a maximum output speed of 172 RPM. The cast iron housing has an epoxy coating system finish, and the unit supports a maximum input of 2 hp and a maximum output torque of 687 in-lb.
Confirm the part number against your existing unit or equipment before ordering to ensure correct fit.
