- Input Connection Type: C-Face
- Gear Type: Worm
- Output Shaft Type: Keyed
- Maximum Output Speed: 115 RPM
- Motor: Frame Designation 56C
- Worm Center Distance: 1.33 in
Specifications
| Part Number | E13MWNS, 15:1, 56C |
| Brand | Winsmith |
| Item | Speed Reducer |
| Input Connection Type | C-Face |
| Gear Type | Worm |
| Output Shaft Type | Keyed |
| Maximum Output Speed | 115 RPM |
| Motor | Frame Designation 56C |
| Worm Center Distance | 1.33 in |
| Base to Center | 1.75 in |
| Gear Ratio | 15:1 |
| Rotation | CW/CCW |
| Maximum Input Horsepower | 0.5 hp |
| Maximum Output Torque | 238 in-lb |
| Overhung Load Capacity | 290 lb |
| Mounting Orientation | Any Angle |
| Housing Material Cast | Iron |
| Housing Material Finish | Epoxy Coating System |
Description
The Winsmith E13MWNS, 15:1, 56C is a worm gear speed reducer with a C-face input connection for a 56C frame motor. It has a 15:1 gear ratio, a keyed output shaft, and a maximum output speed of 115 RPM. The cast iron housing has an epoxy coating finish, and the unit can be mounted at any angle.
Confirm the part number against your existing unit or equipment before ordering to ensure correct fit.
