- Amps: 20 A
- AC Voltage Rating: 240V AC
- Max. AIR Rating: 25kA at 277/408V AC
- For Use With: Electrical Distribution Equipment
- Industrial Control: Panels
- Series: BDL
Specifications
| Part Number | BDL16020 |
| Brand | Square D |
| Item | Molded Case Circuit Breaker |
| Amps | 20 A |
| AC Voltage Rating | 240V AC |
| Max. AIR Rating | 25kA at 277/408V AC |
| For Use With | Electrical Distribution Equipment |
| Industrial Control | Panels |
| Series | BDL |
| Circuit Breaker Type | Standard |
| Number of Poles | 1 |
| DC Voltage Rating | Not Rated |
| Terminal Connection | Everlink Lug Both Ends |
| Trip Type | Thermal Magnetic |
| Phase | Single |
| Instantaneous Trip | Fixed |
| Phase Connection | Any |
| Frame Size | 125A/BD |
| Circuit Breaker Mounting Style | Unit Mount |
| Height | 5.39 in |
| Width | 1.06 in |
| UPC | 785901018919 |
Description
The Square D BDL16020 is a molded case circuit breaker from the POWERPACT B Series. It is rated for 20 A, 1 pole, and 347/600V AC, with a maximum AIR rating of 25kA at 277/408V AC. This standard thermal magnetic breaker has a B curve, a 125A/BD frame size, and Everlink lug terminals on both ends.
Confirm the part number against your existing unit or equipment before ordering to ensure correct fit.
