- Heat Sink: Not Included
- Input Voltage: 90 to 140V AC
- Maximum Output Current with Heat Sink: 50 A
- Maximum Output Current without Heat Sink: Not Recommended
- Output Switching Mode: Zero Crossing
- Output Voltage Range: 48 to 530V AC
Specifications
| Part Number | B53TP50CH |
| Brand | Crydom |
| Item | Solid State Relay |
| Heat Sink | Not Included |
| Input Voltage | 90 to 140V AC |
| Maximum Output Current with Heat Sink | 50 A |
| Maximum Output Current without Heat Sink | Not Recommended |
| Output Switching Mode | Zero Crossing |
| Output Voltage Range | 48 to 530V AC |
| Standards | CE Certified, UL Listed |
| Switch Component Type | SCR |
| Current Type | AC |
| Finger Safe | Yes |
| Mounting Style | Surface |
| Switch Configuration Form | A |
| Voltage Type AC | Output |
| Body Depth | 3.2 in |
| Body Height | 1.45 in |
| Body Width | 4.09 in |
| Case Color | Gray |
Description
The Crydom B53TP50CH is a three-phase solid state relay with an SCR switch component type and zero-crossing output switching. It accepts an input voltage of 90 to 140V AC and provides an output voltage range of 48 to 530V AC, with a maximum output current of 50 A when used with a heat sink. This surface-mount relay has a gray case measuring 3.2 in deep, 1.45 in high, and 4.09 in wide, and is CE Certified and UL Listed.
Confirm the part number against your existing unit or equipment before ordering to ensure correct fit.
