- Amps: 10 A
- Contact Form: DPST-4NC
- VA Rating: 460V AC
- Float Travel: 1 1/4 in
- NEMA Rating: 7
- Operating Temp.: Range -22 Degrees to 220 Degrees F
Specifications
| Part Number | 9038AR1 |
| Brand | Telemecanique Sensors |
| Item | Alternator Open Liquid Level Switch |
| Amps | 10 A |
| Contact Form | DPST-4NC |
| VA Rating | 460V AC |
| Float Travel | 1 1/4 in |
| NEMA Rating | 7 |
| Operating Temp. | Range -22 Degrees to 220 Degrees F |
| Switch Function | Close On Rise |
| Overall Length | 11.88 in |
| Float Material | Stainless Steel |
| Float Length | 7 in |
| Float Dia. | 7 in |
| Height | 6.86 in |
| Width | 5.35 in |
| Max. Current | 600 A |
| Max. Voltage | 600 |
| hp | HP @ 1 Phase - 120V 2 |
| hp | HP @ 1 Phase - 240V 3 |
| hp | HP @ 3 Phase - 240V 5 |
| Open | Tank Mounting |
| Body Material | Aluminum |
| Features | 9 |
| UPC | 785901591054 |
Description
The Telemecanique Sensors 9038AR1 is a DPST-4NC alternator open liquid level switch with a close-on-rise function. It has a stainless steel float measuring 7 inches in diameter and length, with 1 1/4 inches of float travel. The aluminum body is rated NEMA 7, with an operating temperature range of -22 to 220 degrees F and a maximum voltage of 600V AC.
Confirm the part number against your existing unit or equipment before ordering to ensure correct fit.
