- Motor Design: 3-Phase
- Phase: Three
- HP: 1
- No. of Speeds: 1
- Voltage: 208-230/460V AC
- Motor Shaft Rotation: CCW
Specifications
| Part Number | 1830V |
| Brand | U.S. Motors |
| Item | Motor,1HP,825RPM,208-230/460V,56YZ |
| Motor Design | 3-Phase |
| Phase | Three |
| HP | 1 |
| No. of Speeds | 1 |
| Voltage | 208-230/460V AC |
| Motor Shaft Rotation | CCW |
| Frame | 56 |
| Motor Enclosure Design Totally Enclosed | Air-Over |
| Band Motor Mounting | Type |
| Shaft Length | 3 1/4 in |
| Motor Thermal Protection | None |
| Max. Ambient Temp. | 60 Degrees C |
| Nameplate RPM | 825 |
| Hz | 60 |
| Full Load Amps | 5.2-5.2/2.6 A |
| Ins. Class | F |
| Motor Service Factor | 1 |
| Overall Length | 13 1/2 in |
| Features | HVAC/R |
| UPC | 786382080372 |
Description
The U.S. Motors 1830V is a 1 hp condenser fan motor operating at 825 rpm. This three-phase unit runs on 208-230/460V AC and features a 56 frame with a totally enclosed air-over design. It has a shaft length of 3 1/4 in, an overall length of 13 1/2 in, and a maximum ambient temperature of 60 degrees C.
Confirm the part number against your existing unit or equipment before ordering to ensure correct fit.
