- Body Dia.: 7.4 in
- Bolt Circle Dia.: 5 7/8 in
- Conduit Box Location: Exterior
- Conduit Box Position: F3
- Duty Cycle: Continuous
- Frame: 56HC
Specifications
| Part Number | 056B17F5310 |
| Brand | Leeson |
| Item | Pressure Washer Motor |
| Body Dia. | 7.4 in |
| Bolt Circle Dia. | 5 7/8 in |
| Conduit Box Location | Exterior |
| Conduit Box Position | F3 |
| Duty Cycle | Continuous |
| Frame | 56HC |
| Hz | 60 Hz |
| Full Load Amps | 13.6/7.5-6.8 |
| Height | 9 in |
| HP | 1 1/2 |
| Ins. Class | B |
| Length Less Shaft | 11 15/16 in |
| Max. Ambient Temp. | 40 Degrees C |
| Motor Application Pressure | Washer |
| Motor | Bearings Ball |
| Motor Design | Capacitor-Start/Run |
| Motor Enclosure Design Totally Enclosed | Fan-Cooled |
| Motor Frame Material | Steel |
Description
The Leeson 056B17F5310 is a 1 1/2 HP pressure washer motor operating at 1725 RPM. It has a 56HC steel frame, a totally enclosed fan-cooled design, and a continuous duty cycle. This capacitor-start/run motor is rated for 115/208-230V, 60 Hz, with full load amps of 13.6/7.5-6.8 and Class B insulation.
Confirm the part number against your existing unit or equipment before ordering to ensure correct fit.
