- Voltage: 90-240V AC
- Phase: Single
- Max. Ambient Temp.: 55 Degrees C
- RPM Range: 1,501-1,600
- Voltage Compatibility: 90-240V AC
- Hz: 60 Hz
Specifications
| Part Number | MD5472 |
| Brand | Genteq |
| Voltage | 90-240V AC |
| Usable @ 200V | Yes |
| Phase | Single |
| Weight | 5 lb |
| Max. Ambient Temp. | 55 Degrees C |
| Bolt Circle Dia. | 9 4/5 in |
| Overall Length | 4 3/8 in |
| Shaft Length | 5/16 in |
| Cord Length | 23 in |
| Body Dia. | 10 1/8 in |
| Shaft Dia. | 1/4 in |
| Manufacturers Warranty Length | 1 yr |
| Item | COMMERCIAL REFRIGERATION MOTOR |
| Replacement For | 05472, 5R028, 5R037, EC5472FP |
| Conduit Box Location | No |
| RPM Range | 1,501-1,600 |
| Motor Application | HVAC/R |
| No. of Speeds | 1 |
| Extended Thru-Bolts | No |
| Voltage Compatibility | 90-240V AC |
| Bearing Protection | Moisture Shield |
| Capacitor Required | No |
| Motor Mounting Position | Horizontal or Vertical Shaft Up |
| Duty Cycle | Continuous |
| Motor Thermal Protection | Auto |
| Motor Shaft Rotation | CWSE |
| Hz | 60 Hz |
| Full Load Amps | 0.55-0.3 A |
| Motor Design | ECM |
| Nameplate RPM | 1,550 |
| Conduit Box Position | No |
| Motor Bearings | Ball |
| Frame | Unit Bearing |
| Motor Mounting Type | Shroud |
| Inverter Rated | No |
| Removable Base | No |
| Plug Type | 2 Prong Non-Polarized |
| Motor Enclosure Design | Totally Enclosed |
| Ins. Class | B |
| Motor Flange Type | Non-Ventilated |
| Motor Frame Material | Aluminum |
| Motor Service Factor | 1 |
| Features | Straight Plug |
| Usable @ 208V | Yes |
| Motor Sub Application | Refrigerator/Freezer |
| Output Watts | 4 to 20 W |
| Motor Shaft Design | Threaded |
Description
The Genteq MD5472 is a commercial refrigeration motor. This motor drives the fan in refrigeration equipment to circulate air over the coils. It operates on 90-240V AC single-phase power, has a 1,501-1,600 RPM range, and does not require a capacitor.
